TECHNICIAL SPECIFICATIONS
|
Techical
Specifications
|
MACHINE MODEL |
|
700 X 300 mm
|
700 X 300 mm
|
1000 X 500 mm
|
1400 X 500 mm
|
|
Max. Part Width
|
700 mm
|
700 mm
|
1000 mm
|
1400 mm
|
|
Quantities Of Turbines
and Power
|
1 x 11 KW
|
2 x 11 KW
|
2 x 11 KW
|
2 x 11 KW
|
|
Disc Diameter
|
400 mm
|
400 mm
|
400 mm
|
400 mm
|
|
Drive Type
|
Kayış Kasnaklı
|
Kayış Kasnaklı
|
Kayış Kasnaklı
|
Kayış Kasnaklı
|
|
Work Speed
|
1 - 10 m/min
|
1 - 10 m/min
|
1 - 10 m/min
|
1 - 10 m/min
|
|
Total Power
|
34 KW
|
45 KW
|
54 KW
|
65 KW
|
* Machine can be manufactured in desired size and size.
